Inertial Sensing

Survey Instruments

The gyro instruments leading the way in innovation, accuracy and development in the industry. Inertial Sensing develops standard, non-integrated and fully integrated gyros for multiple industries. Whether you are in core drilling, oil/gas, infrastructure or mining, we have tools that fit your needs.

logo

Integrated

Integrated 25mm SlimTwin Gyro

Ultra-Rugged SlimTwinGyro TechnologySlimTwin - is the world’s slimmest rate gyro survey instrument. Fully integrated with a diameter of only 25 mm it offers a truly unique two-gyros-in-one ultra-slim package.Low Power Consumption -With its extremely low power consumption the tool can survey for up to 50 hours on a single battery charge.User Friendly - No special pre- or post-survey procedures are necessary to get into the hole. The simple set-up saves valuable site-time and potential sources of human error are significantly reduced.Survey Security- The SlimTwin combines two independent survey systems in one instrument. Where a standard tool completes one survey, the SlimTwin delivers two independent surveys.

Product Sheet

Integrated 35mm Twin Gyro

Fully-Integrated Rugged Dual Gyro TechnologyInnovation - The fully integrated TwinGyro offers our unique two-gyros-in-one technology in a rugged 35 mm package. It is ideal for surveying where hole diameter is not an issue and getting two surveys per run significantly cuts rig downtime.Versatile - Available in multiple configurations including overshot for easy use in coring.Survey Security- The Twin combines two independent survey systems in one instrument. Where a standard tool completes one survey, the Twin delivers two independent surveys.

Product Sheet

Integrated 35mm GoGyro

Fully-Integrated Rugged Gyro TechnologySimply go survey!Versatile - Available in three standard configurations for the most common applications:-core retriever-wireline-centralizersAccessories -Every configuration is based around the standard GoGoGyro tool and the accessories are easily switched between units if necessary.User Friendly - No special pre- or post-survey procedures are necessary to get into the hole. The simple set-up saves valuable site-time and potential sources of human error are significantly reduced. The modular design of the tool minimizes repair times and cost.

Integrated Compass

Based on modern MEMS technology - The Compass is a magnetic multishot instrument for borehole surveying based on modern MEMS technology. It is fully integrated in its own brass running gear, requiring little set-up in the field. Wireless in operation, the tool utilizes infrared communication with a rugged handheld field computer. Compass is powered by standard C battery cells and will operate for more than 100 hours on seven batteriesisCompass specifications - The tool outputs standard survey data, such as recorded station depth, inclination, azimuth, gravity highside, magnetic toolface, temperature and more. The magnetometers have been calibrated with high precision and the tool will deliver a reading of the magnitude of the local magnetic field which can be used to detect anomalies in the local Earth magnetic field to identify survey stations of low quality. Local magnetic declination and start coordinates can also be set directly in the handheld unit. The OD of the fully-integrated running gear is 35 mm and the system is supplied with three aluminum extension rods to allow the operator to get the gear through and away from the drill bit.

Product Sheet

Non Integrated

Non-integrated TwinGyro™

Ultra-Rugged Dual Gyro TechnologySurvey security- The TwinGyro™ combines two independent survey systems in one instrument. Where a standard tool completes one survey, the TwinGyro™ delivers two independent surveys.Independent backup - The system contains a built-in backup - the TwinGyro™ can be run in single gyro mode and continue operating even if one system has been damaged.Low power consumption - The TwinGyro™ has a power consumption of only 0.4 W. The system can also be used in single mode to preserve power. An additional delayed start mode allows the system to be initialized in 5 mW sleep mode to wake up for surveying after a pre-set time.Fast continuous survey mode - All new versions of Inertial Sensing gyros are capable of running in both standard multi-shot mode as well as the new fast continuous survey mode. Survey data from a continuous survey can easily be reprocessed to any required station interval.

Product Sheet

Non-integrated SlimGyro™

World's smallest MEMS memory rate gyro systemSlimGyro - is the world's smallest rate gyro survey instrument. With a diameter of only 21.56 mm and a running gear diameter of 26 mm, it offers high accuracy in even the tightest holes.Low power consumption - With an amazingly low power consumption of 0.2 W the tool can survey for up to 80 hours on a single battery charge. An additional delayed start mode allows the system to be initialized in 5 mW sleep mode to wake up for surveying after a pre-set time.Fast continuous survey mode - All new versions of Inertial Sensing gyros are capable of running in both standard multi-shot mode as well as the new fast continuous survey mode. Survey data from a continuous survey can easily be reprocessed to any required station interval.

Product Sheet

Non-integrated StandardGyro

StandardGyro - The StandardGyro is a user-friendly borehole survey tool that offers you high accuracy in mining and geotechnical applications. Download and processing times are fast and the tool can survey for up to 80 hours on a single battery charge. No special pre- or post-survey procedures are necessary to get into the hole. The simple set-up saves valuable site-time and potential sources of human error are significantly reduced. The modular design of the tool minimizes repair times and cost.Low power consumption - With an amazingly low power consumption of 0.2 W the tool can survey for up to 80 hours on a single battery charge. An additional delayed start mode allows the system to be initialized in 5 mW sleep mode to wake up for surveying after a pre-set time.Fast continuous survey mode - All new versions of Inertial Sensing gyros are capable of running in both standard multi-shot mode as well as the new fast continuous survey mode. Survey data from a continuous survey can easily be reprocessed to any required station interval.

Product Sheet

BlastGyro™

The BlastGyro™ is a unique survey system designed for efficient surveying of production blastholes. At the heart of the system is the world's smallest survey gyro - the SlimGyro™ - and its light weight and compact running gear. The length of the mounted gyro and running gear is 138 cm, with an outer diameter of only 26 mm and a total tool string weight of 4.5 kg.Light Weight- The compact size of the system makes it safe and easy to manually run in and out of blastholes using a feeder reel fitted with 50 meters of 11 mm fiberglass rod. The BlastGyro™ can survey at all angles and the fiberglass rod assures it can be moved up, down and horizontally.

Product Sheet

Non-integrated North Finder

True MEMS gyro compass - The NorthFinder is based on MEMS gyro sensors which gives a rugged survey system in a 32 mm housing. The NorthFinder takes independent readings at survey stations, giving the gyro toolface and azimuth and also provides inclination as well as gravity highside. The main purpose of the NorthFinder is to serve as an independent reference together with the StandardGyrofor deep vertical boreholes.Low power technology- The NorthFinder has a very low power consumption due to being based on MEMS sensors, consuming as little as 1 W of power. This is especially useful when running the instrument in a heat shield as it vastly improves the downhole time, generating very little heat compared to competing systems.Fast WiFi transfer- The gyro compass and accelerometer data are transferred to the field computer using WiFi which ensures very fast data transfer. The transfer time is less than a minute even for large surveys. The NorthFinder survey software is easy to use and install. The survey software runs on multiple Windows platforms including XP, 7, 8, 10 on both 32 and 64-bit systems.

Product Sheet

Compass

Based on modern MEMS technology - The Compass is a magnetic multishot instrument for borehole surveying based on modern MEMS technology. It is fully integrated in its own brass running gear, requiring little set-up in the field. Wireless in operation, the tool utilizes infrared communication with a rugged handheld field computer. Compass is powered by standard C battery cells and will operate for more than 100 hours on seven batteriesisCompass specifications - The tool outputs standard survey data, such as recorded station depth, inclination, azimuth, gravity highside, magnetic toolface, temperature and more. The magnetometers have been calibrated with high precision and the tool will deliver a reading of the magnitude of the local magnetic field which can be used to detect anomalies in the local Earth magnetic field to identify survey stations of low quality. Local magnetic declination and start coordinates can also be set directly in the handheld unit. The OD of the fully-integrated running gear is 35 mm and the system is supplied with three aluminum extension rods to allow the operator to get the gear through and away from the drill bit.

Product Sheet

Accessories

Running Gear

We offer a 38mm and a 26mm that fit our TwinGyro, Gyro and SlimGyro.- Pressure barrel- Top plug with tool hanger- Bottom plug with shock absorber- Swivel- Anti-roll bar- 3 V-blocks- 30-mm Spanners

Wireless Depth Tracker

A standalone wireless depth tracker with a fixture for mounting on the drill rod collar.-Bluetooth communication-Long battery life-Light weight-0.1% depth accuracy-Up to 12 mm wireline diameter-100 m/min wireline speed

Mazac Smart Aligner

A lightweight and smartphone enabled drill rig GPS alignment solution for surface applications.-0.5 deg azimuth accuracy-0.2 deg tilt and roll accuracy-Fast acquisition time-Operated with Android app-Ten hours operation on a single charge-Foldable and easy to transport

ADW600 SURVEY WINCH

The ADW600 is a compact and portable winch from Gyro-Service's for borehole surveys and logging.The main components are:-Encoder interface to Surveyor software available on request-Helicoidal spindle for automatic laying of cable on drum-Electronic depth encoder with display-Frequency controlled asynchronous electric motor (0.75 kW)-Electric motor brake that keeps the wireline absolutely still at stations-600 m of stainless steel wire

Tripod

A lightweight tripod from Gyro-Services that allows a single operator to execute a survey in vertical a borehole when the drill rig has already left.  The kit consists of:-Detachable pulley-Telescopic legs-Adjustable ties-3 ground anchors

Sighting Device

A sighting device is required for vertical surveys to align with a known reference direction.The Polymetra sighting device for the Gyro is stored in a Peli Case 1400. It consists of:-Rifle scope mounted on a special bracket holding 3 spirit levels-Clamp (can be attached to any spanner face of the running gear)-Locking plate(For surveys in underground, a sighting device with two laser beams is available).

Inline Centralizers

Centralizers are required for vertical surveys to prevent the tool from spinning. The design of inline centralizers prevents the tool from blocking when surveying open holes as the blades can deform to a minimum diameter of 38 mm. Polymetra's inline centralizers are designed for the isRG38 running gear.The standard kit consists of:-2 centralizer bodies with shaft and sliding end-Bow springs for borehole diameter 3", 4" and 5" (8 each)-19-mm spanner-Plastic tube to assist mounting of spring blades
